| Camera |
| Image Sensor: |
| |
1/2.5" Progressive Scan CMOS |
| Signal System: |
| |
PAL/NTSC |
| Min. Illumination: |
| |
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Color: 0.014 Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Shutter time: |
| |
1/3 s to 1/100,000 s |
| Slow shutter: |
| |
Support |
| Lens: |
| |
2.8 to 12 mm |
| Lens Mount: |
| |
φ14 |
| Adjustment Range: |
| |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Day& Night: |
| |
IR cut filter with auto switch |
| Wide Dynamic Range: |
| |
120 dB |
| Digital noise reduction: |
| |
3D DNR |
| Focus: |
| |
Motorized VF lens(-Z model) |
| Compression Standard |
| Video Compression: |
| |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
| |
32Kbps~16Mbps |
| Audio bit rate: |
| |
32 to 128kbps |
| Triple Streams: |
| |
Yes |
| Image |
| Max. Image Resolution: |
| |
3840 × 2160 |
| Frame Rate: |
| |
50Hz: 20 fps (3840 × 2160), 25 fps (2944 × 1656, 2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3840 × 2160), 30 fps (2944 × 1656, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream: |
| |
50Hz: 25fps (640 × 360, 352 × 288)
60Hz: 30fps (640 × 360, 352 × 240) |
| Third Stream: |
| |
50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240) |
| Image Enhancement: |
| |
BLC/3D DNR |
| Image Settings: |
| |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Target Cropping: |
| |
Support |
| ROI: |
| |
Support 1 fixed region for each stream |
| Day/Night Switch: |
| |
Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage: |
| |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
| |
Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login |
| Protocols: |
| |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: |
| |
One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video
mask, Watermark, IP address filtering |
| System Compatibility: |
| |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
|
Interface
|
| Communication Interface: |
| |
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
| |
Yes |
| Audio |
| Environment Noise Filtering: |
| |
Support |
| Smart Feature-set |
| Behavior Analysis: |
| |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Line Crossing Detection: |
| |
Cross a pre-defined virtual line |
| Intrusion Detection: |
| |
Enter and loiter in a pre-defined virtual region |
| Unattended Baggage: |
| |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: |
| |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Recognition: |
| |
Face Detection |
| General |
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
| |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: |
| |
12 VDC, 1.5A, max. 17W
PoE (802.3at, 42.5V to 57V), 0.1A to 0.5A, max. 19W |
| Weather Proof: |
| |
IP67 |
| IR Range: |
| |
Up to 50m |
| Dimensions: |
| |
Φ144.13×332.73 mm (Φ5.67"× 13.10") |
| Weight: |
| |
Camera: 1893 g (4.17 lb.) |
