• False alarm filtering for up to 16-ch behavior detection
• 320/256 Mbps bit rate input/output(up to 32-ch IP camera input)
• Up to 12MP resolution recoding/live view
• H.265+/H.265/H.264+/H.264 video formats self-adapt
• 8-ch 1080P decoding capability
• HDMI output at up to 4K resolution
• Up to 8 SATA interfaces, up to 8 TB for each HDD
• HDD hot swapping with RAID 0/1/5/6/10
| Video/Audio Input |
| IP video input: |
| |
32-ch |
| Two-way audio input: |
| |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth: |
| |
320Mbps or 200Mbps(when RAID is enabled) |
| Outgoing bandwidth: |
| |
256Mpbs or 200Mbps(when RAID is enabled) |
| Video/Audio Output |
| HDMI/VGA output: |
| |
2-ch, resolution:
HMDI1/VGA1:HDMI1: 4K (3840 × 2160)/60Hz,
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI2/VGA2:1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| CVBS Output: |
| |
1-ch, BNC(1.0Vp-p, 75Ω)
Resolution: 704×576(PAL); 704×480(NTSC) |
| Synchronous Playback: |
| |
16-ch |
| Decoding |
| Live view / Playback: |
| |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: |
| |
8-ch@1080P |
| Hard Disk |
| SATA: |
| |
8 SATA interfaces for 8 HDDs |
| eSATA: |
| |
1 eSATA interface |
| Capacity: |
| |
Up to 8TB capacity for each HDD |
| Disk array |
| Array type: |
| |
RAID0, RAID1, RAID5, RAID6, RAID10 |
| Number of array: |
| |
4 |
| External Interface |
| Network Interface: |
| |
2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface: |
| |
RS-232, RS-485, Keyboard |
| USB Interface: |
| |
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0 |
| Alarm In: |
| |
16-ch |
| Alarm Out: |
| |
4-ch |
| POE |
| Max. Power: |
| |
200W |
| General |
| Power Supply: |
| |
100 to 240 VAC, 50 to 60 Hz |
| Consumption(without hard disk and POE): |
| |
≤ 70 W |
| Working Temperature: |
| |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: |
| |
10 % ~ 90 % |
| Chassis: |
| |
19-inch rack-mounted 2U chassis |
| Dimensions: |
| |
445 × 470 ×90 mm (17.5"× 18.5" × 3.5") |
| Weight(without HDD): |
| |
≤ 10 kg (22 lb) |
