| Camera |
| Image Sensor: |
| |
1/1.9" HD CMOS sensor |
| Horizontal Resolution: |
| |
4096x2160 |
| Signal System: |
| |
PAL/NTSC |
| Minimum Illumination: |
| |
F1.5, 50IRE, AGC On: Color: 0.02 lux, B/W : 0.002 lux, 0 lux with IR |
| White Balance: |
| |
Auto / Manual |
| AGC: |
| |
Auto/Manual |
| BLC: |
| |
ON/OFF |
| HLC: |
| |
Support |
| Smart defog: |
| |
Support |
| WDR: |
| |
Support |
| Shutter Time: |
| |
50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
| Day& Night: |
| |
ICR |
| Digital Zoom: |
| |
16X |
| Privacy Masking: |
| |
24 privacy masks programmable |
| Auto Focus: |
| |
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
| |
5.7-205.2mm, 36x |
| Zoom Speed: |
| |
Approx.7.4s(Optical Wide-Tele) |
| Angle of View: |
| |
56.8-2.02 degree (Wide-Tele) |
| Minimum Working Distance: |
| |
10-1500mm(Wide-Tele) |
| Aperture Range: |
| |
F1.55~F4.8 |
| Pan & Tilt |
| Pan Range: |
| |
360°endless |
| Pan Speed: |
| |
Pan Manual Speed: 0.1°~160°/s, Pan Preset Speed: 240°/s |
| Tilt Range: |
| |
-20°~90°(Auto Flip) |
| Tilt Speed: |
| |
Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 200°/s |
| Proportional Zoom: |
| |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
| |
300 |
| Patrol: |
| |
8 patrols, up to 32 presets per patrol |
| Pattern: |
| |
4 patterns, with the recording time not less than 10 minutes per pattern |
| Power loss recovery: |
| |
Support |
| Park Action: |
| |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| Freeze Frame: |
| |
Support |
| Smart-tracking: |
| |
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger |
| Wiper: |
| |
Optional |
| Infrared |
| IR irradiation distance: |
| |
500m |
| IR irradiation angle: |
| |
Adjustable by zoom |
| Alarm |
| Alarm Input: |
| |
7 Inputs |
| Alarm Output: |
| |
2 |
| Alarm Actions: |
| |
Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Network |
| Ethernet: |
| |
10Base -T, /100Base-TX, RJ45 Connector |
| Main Stream: |
| |
50Hz:25fps(4096×2160, 3840×2160, 3072×1728, 2560×1440, 1920×1080, 1280×720)
60Hz:24fps(4096×2160), 30fps(3840×2160, 3072×1728, 2560×1440, 1920×1080, 1280×720) |
| Sub Stream: |
| |
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: |
| |
50Hz: 25fps(704×576, 640×480, 352×288);
60Hz: 30fps(704×480, 640×480, 352×240) |
| Image Compression: |
| |
H.264 / MJPEG |
| ROI encoding: |
| |
Support 6 areas with adjustable levels |
| Audio Compression: |
| |
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Audio Mode: |
| |
OFF/Audio input/Audio output |
| Protocols: |
| |
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| No. of Simultaneous Users: |
| |
Up to 20 users |
| Three-Stream: |
| |
Support |
| Mini SD Card: |
| |
Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording |
| User/Host Level: |
| |
Up to 32 users,3 Levels: Administrator, Operator and User |
| Security Measures: |
| |
User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering |
| Client GUI |
| Camera Control: |
| |
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: |
| |
Time: Week: Date, 6 formats on the Client |
| Client: |
| |
Support iVMS-4200 |
| Web Browser: |
| |
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language |
| General |
| RS-485 Protocols: |
| |
Pelco-P, Pelco-D, self-adaptive |
| Menu Language: |
| |
English |
| Power Supply: |
| |
High-PoE&24 VAC, Max.60W |
| Power Consumption: |
| |
Max.60W |
| Working Temperature/Humidity: |
| |
-40°C ~ 65°C (-40°F ~ 149°F) |
| Protection Level: |
| |
IP66, IK10, TVS 6,000V lightning protection, surge protection and voltage transient protection |
| Dimensions: |
| |
Φ266.6(mm)×435(mm) |
| Weight (approx.): |
| |
8kg (approx.) |
| Mount Option: |
| |
Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner;
Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ |
